- 27″ to 32″ ViewZ Monitors
- Load Capacity is 165 lbs / 75.0 kg
- Universal Mounting – 200 x 200(Min) ~ 400 x 200(Max)
- -10°~0° Tilt Low Profile Wall Mount
Specification | Dimension | Spec & Manual
Series : Wall Mount | Key Features : Compatible for 27-32″
Compatible Monitors
Product Features
- Model Number: VZ-WM50
- 27″ ~ 32″ Flat Wall Mount
- Universal Mounting Pattern
- VESA Standard Mounting Hole – 200×200 and 400×200
- Black Metal
Specification
| Display Range | 27″ ~ 32″ |
| Weight Capacity | 165 lbs / 75 kg |
| Profile | 1.77″ / 45 mm |
| Tilt | 10° ~ 0° |
| Mounting Pattern Type | VESA, Universal |
| Mounting Patterns | 200 x 200 (Min), 400 x 200 (Max) mm |
Dimensions & Weight
| Dimension (W x H x D) | 464 mm x 270 mm x 45 mm / 18.26″ x 10.62″ x 1.77″ |
| DIM Size (W x H x D) | 464 mm x 203 mm x 15 mm / 18.26″ x 7.99″ x 0.59″ |
| Net Weight (with Holder) | 3 lbs (1.36 kg) / 4 lbs (1.81 kg) |
| Gross Weight | 5 lbs / 2.26 kg |
Product Dimension & Weight
Click below to enlarge
