98″ Interactive 4K Touch Monitor

product Description
Loading image... Loading image... Loading image... Loading image...

VZ-IBX-T series can unleash new and exciting possibilities at the touch of a finger. These large size 4k monitors are touch screen, making them perfect for school and presentation digital whiteboards while also catering to digital signage and security application. The future is now with IBX series touch screen monitors.

  • 97.5” LED ULTRA HD Monitor
  • Supports 4K (3840X2160) Resolution
  • 20-Point Multi Touch Interactive Screen
  • USB – Built in Media Player
  • Variable Inputs Support (HDMI, YPbPr, AV, VGA)
  • HDMI & AV Loop-through, Auto Source Recovery
  • Wide Viewing Angle (IPS Panel)
  • 1.07G Color & QFHD

Specification | Dimension | Download

Series : IBX-T | Key Features : 4K Touch Screen

Compatible Mounts & Accessories

Product Features

  • Model Number: VZ-98IBX-T
  • 97.5″ LED UHD Panel
  • 4K Resolution – 3840×2160 / 16:9
  • Wide Viewing Angle (IPS Panel)
  • 20-Point Multi Touch Interactive Screen
  • HDMI & AV Loop-through
  • USB – Media Player
  • Auto Source Recovery
  • Supported HDMI (2.0 & 1.4), AV, SPDIF & VGA

Display

Screen Size 97.52″
Max Resolution 3840 x 2160 @60Hz
Pixel Pitch 0.5622 mm x 0.5622 mm
Brightness 500 cd/m²(Typical)
Contrast Ratio 1300 : 1
Aspect Ratio 16 : 9 (1.78 : 1)
Viewing Angle (H/V) 178°/178°
Display Color 1.07G
Response Time < 8ms


Interface

HDMI (2.0) In / Out 4 / 1
HDMI (1.4) In 1
YPbPr In 1
AV In / Out 1 / 1
VGA In (15Pin D-Sub) 1
SPDIF (Optical) Out 1
RS232 (RJ-45) In 1
USB In (Media) 5 ( USB 3.0 x 3 | USB 2.0 x 2 )
USB In (Under OPS – Mouse, Keyboard, U-Disk) 2
USB In (Touch)) 1
RJ45 (10/100M) In 1
Audio Out 1
PC Audio In 1


Android Board Spec

Android OS Ver 5.0
CPU Quad Core, Cortex-A53, 1.4GHz
RAM 2GB DDR
Storage 8GB (Nand-Flash)


Special Features

Image Retention YES


Media Player

USB Media Player – VIDEO Codec MPEG1/2, MPEG4, DivX 3.11/4.12/5.x/5, XviD, H.263, H.264, MVC, AVS, WMV3, VC1, Motion JPEG, VP8/9, RV30/40
USB Media Player – VIDEO Format MPEG, AVI, MOV, MP4, MKV, RM, 3GP, FLV, WebM, ASP
USB Media Player – Audio Format mp3, mp4, wma
USB Media Player – Image Format JPEG, PNG, BMP
USB Media Player – Capacity Max 32 GB


Touch

Sensor Type Infrared Touch Frame
Surface Protection 4 mm Toughened Glass
Response Time < 10 ms
Touch Accuracy 90% ± 1 mm
Output Mode HID Standard
Theory Clicks Unlimited
Minimum Touch Object ≥ 1.6 mm (Single touch) | ≥ 3 mm (Multi touch)
Infrared Touch 20 Points


Refresh Rate

HDMI (2.0) In 3840 x 2160 @ 60Hz
HDMI (1.4) In 3840 x 2160 @ 30Hz
VGA In (15Pin D-Sub) 1920 x 1080 @ 60 Hz


Audio

Built in Speaker 15W x 2


Dimensions & Weight

Outline Dimension (W x H x D) 88.25” x 52.66 ” x 4.58” / 2241.66 mm x 1337.8 mm x 116.4 mm
Net Weight 307.39 lbs / 139.43 kg
Gross Weight 424.72 lbs / 192.65 kg


Mount

Universal Wall Mount 800 x 600 mm / M8 x 4


General Summary

Transmitter – IR Remote Control Yes
Housing Sheet Black Aluminium
Power – Electrical Ratings AC 100-240V (50/60Hz)
Power – Consumption ≤ 480 W / ≤ 0.5 W (Standby)
Regulations FCC(A), WEEE
Operating Temperature | Humidity 32 ~ 104°F / 0 ~ 40°C | 20 ~ 80% RH
Storage Temperature | Humidity 14 ~ 140°F / -10 ~ 60°C | 10 ~ 60% RH
Language (OSD) English
Regulations FCC (A), RoHS
Accessories Manual (1pc), Power Cable (1pc), USB Cable (1pc), Remote Controller (1pc), Wall Mount (1set), Touch Pen (2pc), HDMI Cable (1pc), Mobile Stand (Option)


Product Dimension & Weight
