VZ-OPS
OPS Based WINDOWS PC Unit
- Compatible with VZ-UHD Series
- Custom Interface / Specification is available
- Powerful system with the Intel® Core™ i5 7200U processor, 8GB (Upto 16GB) DDR4 RAM &128GB (Upto 512GB) SSD storage
- Support HDMI Out 4K @60Hz
- Support USB 3.0 x2, USB 2.0 x2 & USB Type-C x1
- Plug & Play System
- NDAA Compliant
Specification | Dimension | Spec & Manual
Key Features : 4K
Compatible Monitors
Product Features
- Model Number: VZ-OPS
- Compatible with VZ-UHD Series
- Custom Interface / Specification is available
- Powerful system with the Intel® Core™ i5 7200U processor, 8GB (Up to 16GB) DDR4 RAM &128GB (Up to 512GB) SSD storage
- Complete network support WiFi 2.4GHz/5GHz, bluetooth, and gigabit LAN ethernet
- Supports 4K (3840X2160) resolution
- Selectable Window OS system
- Enhanced thermal design supports broader range of Intel® processors
- Enables new and customizable functionality through an additional connector interface that can be enhanced further with Intel® FPGAs
- Optimized for interactive white boards (IWBs), commercial digital signage, kiosks, visual data devices, video walls, and more
- Ability to customize a protocol and simultaneously support advanced use cases including real-time analytics and video capture performed on the display itself
Specification
| Processor | Intel® Mobile Core™ i5 7200U |
| Socket | Intel® Socket Support (Coffee Lake-U) |
| Chipset | Intel® Coffee Lake-U |
| RAM | 8GB DDR (Up to 16GB) |
| Storage | 128GB SSD (Up to 512GB) |
| Graphic | Integrated Intel® Display (Built-in) |
| Sound | Integrated High Definition Audio (Built-in) |
| Wireless 802.11 abgn-AC (2.4GHz/5GHz) | Intel® AC3165 / 2 x Antenna |
| Bluetooth | Above Ver. 4.2 |
Interface
| HDMI (2.0) Out | 1 (support 4K @60Hz) |
| USB 2.0 (Type A) In | 2 |
| USB 3.0 (Type A) In | 2 |
| USB (Type-C) In | 1 |
| RJ45 (10/100/1000 M) In (Gigabit LAN) | 1 / 1 |
| Bluetooth | 1 (Ver. 4.2) |
| PC Audio In / Out | 1 / 1 |
Dimensions & Weight
| Outline Dimension (W x H x D) | 7.87 x 1.14 x 4.65” / 200 x 30 x 118.11 mm |
| Net Weight | 2.2 lbs / 1 kg |
General Summary
| Electrical Ratings | DC 12 ~ 19V (Internal Module) |
| Power – Consumption | ≤ 35 W / ≤ 0.5 W (Standby) |
| Warranty – Parts / Labor | 3 Year / 3 Year |
| Housing | Metal |
| Heating Control | Single Fan |
| TPM (Trusted Platform Module) | Option |
| Intel® vPro™ | Option (Advanced security with multifactor identity protection) |
| Intel® Unite® | Option ( Intel® Unite® Easy Content Sharing ) |
| Operating Temperature | 32 ~ 140°F / 0°C ~ 40°C |
| Operating Humidity | 10 ~ 90% RH |
| Storage Temperature | -4 ~ 140°F / -20°C ~ 60°C |
| Storage Humidity | 10 ~ 90% RH |
Product Dimension & Weight
Click below to enlarge
