VZ-PVM-I5B3/I5W3-N
Full HD Resolution, Built-in 2MP IP Camera compatible with many leading VMS's and NVRs and packed with a long list of other great surveillance and digital signage featured
- 43” Mega Pixel Full HD 1080p IP Public View Monitor
- Onvif Profile-S Compliant
- Recording Available with Micro SD
- People Count / Face Detection (Display Face Detection Boxes) / Mask Detection
- Protective Glass & IPS Panel for Wider Viewing Angle – 178°/178°
- 2 MP Camera & DC Auto Iris 2.8-12 mm Varifocal Lens
- Blinking Message – “Recording in Progress”
- Camera Motion Sensor & Time Interval Based Source Switching
- Auto Power / Source Recovery
- Supports Dual Voltage (110V and 24V DC)
- Built to run 24/7/365
- NDAA Compliant
Specification | Dimension | Spec & Manual
Series : IPPVM-N | Key Features : IP Onvif NDAA Compliant People Count
Compatible Mounts & Accessories
Product Features
- Model Number: VZ-PVM-I5 _ _ N
- 43″ Black/White Panel Widescreen LED “A” Commercial-Grade Monitor
- Full HD 1920×1080 / 16:9
- Recording Available with Micro SD / People Count
- 1920×1080 2 Mega Pixel HD D-WDR Camera
- DC Auto Iris 2.8-12 mm Varifocal Lens
- 720×480 Camera BNC Output
- Motion Sensor and Time Interval based Source Switching
- Alert Text / Multi-Color Blinking LED
- HDMI In / VGA In / AV(Composite) In / Camera (CVBS) Out /
Audio In-Out - 3D Comb Filter / De-Interlace
- Camera and Monitor OSD / Remote Control
- Auto Power & Source Recovery
- VESA Wall Mount 200 x 200
- AC 110V and DC 24V (AC110V-240V with DC adaptor) Dual Voltage
- NDAA Compliant
- Built to run 24/7/365
- 3-Year Warranty
Ordering Information : Parts #
Model Features | Family | Series | Size | Color | Voltage | |
43″, Black, AC 110V / DC 24V | VZ-PVM- | I | 5 | B | 3 | N |
43″, White, AC 110V / DC 24V | VZ-PVM- | I | 5 | W | 3 | N |
- Series: Z (HD PVM) , I (IP PVM)
- Size: 1 (10inch) , 2 (23inch) , 3 (27inch) , 4 (32inch) , 5 (43inch)
- Color: B (Black) , W (White)
- Voltage: 1 (AC110V) , 2 (AC24V), 3 (AC 110V / DC 24V), 4 (PoE)
Display
Screen Size | 43″ |
Max Resolution | 1920 x 1080 @60Hz |
Pixel Pitch | 0.4902 mm x 0.4902 mm |
Brightness | 350cd/m²(Typical) |
Contrast Ratio | 1200 : 1 |
Aspect Ratio | 16 : 9 |
Viewing Angle (H/V) | 178°/178° |
Display Color | 16.7 Million |
Response Time | < 8 ms |
Interface
AV (Composite) In | 1 |
Camera (CVBS) Out | 1 ( 720×480 ) |
Ethernet 10 / 100 | 1 |
RGB In (15pin D-Sub) | 1 |
HDMI In | 1 |
Audio In/Out | 1/1 |
Micro SD In (Recording) | 1 |
DC12V Out (Camera Use) | 1 |
IP Features
Ethernet Interface | 10/100Base-T |
Web Client Protocol | TCP / IP |
Supported Protocol | IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL |
Special Features
Filter Type | 3D Comb filter / De-Interlace |
Blinking Message “Recording” | Yes |
Time Interval Based Source Switching | Yes |
Multi-Lingual Language | English, Spanish, French, German, Italian, Portuguese, Dutch |
People Count / Camera Motion Sensor | Support |
Dimensions
Outline Dimension (W x H x D) | 38.7” x 25.83” x 3.24” / 983mm x 656.2mm x 82.5mm |
Net Weight | 48.5 lbs / 22.0 kg |
Mount
Vesa | 200mm x 200mm / M6 x L8 Screws |
Camera
Image Sensor / Encoder Chipset | SONY IMX307 / NT98520 |
Lens | DC Auto Iris 2.8~12mm Vari-focal Lens |
Total / Effect Pixel | 1920(H) x 1080p(V) 30p |
Camera Type | 2 Mega Pixel IP Camera |
Function | 2D/3D NR, HLC/BLC, Defog, WDR, White Balance, Gain, Noise Reduction, Aisle Mode, Smart IR, Mirror, Privacy Masking, Digital Zoom, Day/Night (Auto ICR), True WDR, Removal Optical Filter |
Video Compression | H.264 (Main profile), H.265, MJPEG, CBR, VBR |
Video Out | 1ch CVBS (NTSC/PAL) / 1ch RJ-45 output |
Motion Detection | Support |
Network Protocol | IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL |
Ethernet Port | 10 / 100 Base-T |
Web Application | Support Firefox, Chrome, Edge |
Intelligent Detection | Perimeter, Single Virtual Fence, Loiter, Converse, Double Virtual Fences, Signal Bad |
Integration Protocol | ONVIF 2.6 (supported), SDK, CGI |
MAX. User Access | 10 Users |
Recording Capacity – TF Card (EXT4 format, MAX256G) | 2MP (H.265 w/256G) – 30fps (11 days) / 15fps (15 days) 2MP (H.264 w/256G) – 30fps (5 days) / 15fps (7 days) |
Media Card Reader - Optional Feature
Support Type | Photo, Music, Video |
External Storage | Support SD/SDHC CARD, USB 2.0 HOST |
Output | VIDEO – HDMI(1080p) / AUDIO – L/R, HDMI |
Video File Format | RM,RMVB(RV30/RV40), VOB(MPEG-2), HDMOV, AVI(DviX, Xvid, MJPEG;MPEG-4 SP/ASP, H.264), DVIX, MPG (MPEG-1, MPEG-2), M4V, PMP, AVC, FLV, MP4 (MPEG-4 SP/ASP, H.264/H.263; Motion JPEG; H.265(720P)), DAT(MPEG-1), MPEG, MOV/MKV(MPEG-4 SP/ASP, H.264/H.263), TS (MPEG-2, H.264, Avs, Avs+), M2TS, WMV, H.264, H.263, WMV9, VC-1, MPEG1/2/4 |
Video Resolution | 1080P @60Hz |
Audio File Format | MPEG1/2/4, MP3, WMA, OGG, AAC, FLAC, APE, AC-3, DTS, ATRA, WAV, PCM |
Image File Format | JPEG, JPG, PNG, BMP |
VIDEO Play Control | AUTO, REPEAT, ZOOM, RESUME, TIME |
General Summary
Transmitter – IR Remote Control | Yes |
Dual Voltage Power – Electrical Ratings | AC 110 ~ 240V | 24V DC, 5A (AC110V ~ 240V with DC adaptor) |
Power – Consumption | ≤ 85 W |
Warranty – Parts / Labor | 3 Year / 3 Year |
Operating Temperature | 14 ~ 122°F / -10 ~ 50°C |
Compatible Mounts – Wall | VZ-WM71 |
Compatible Mounts – Ceiling | VZ-CMKiT-01, VZ-CMKiT-02, VZ-CM308 |
Regulation | FCC(A), CE |
