Video Wall Mount

XMS series mount incorporate 0.050” or 1.27 mm into the spacer, but that is all contingent on the spacer being perfectly placed. Horizontally there is much tolerance because the display slides side to side on the mount, but vertically it is more critical for proper placement.

Each XMS mount can hold up to 154 lb or 70.0kg,
Each WM71 mount can hold up to 165 lb or 75.0kg,
FSM2x2 mount can hold up to 110 lb or 50.0kg,
FSM3x2 mount can hold up to 66 lb or 30.0kg.

Built using rugged materials and high endurance components, ViewZ video wall mounts are made to endure harsh environments and run 24/7 365 in mission critical applications.

Tile & stable articulating pull-out arm allows you to extend the monitor from the wall giving you the ability to position your monitor perfectly.

XMS and FSM series has patent-pending leveling, tilt and in-out adjustment knobs make it easier than ever to flush and level the flat-panels for a seamless video wall. Also, ViewZ WM71 video wall mount supports tilt up and down.

Multiple mounting holes on sliding mounting arm can accommodate various mounting patterns from different size monitors.

ViewZ XMS mount make double locking feature to prevent a display theft.

Simply push the mounting rails in to lock or unlock the mount from the closed position.

ViewZ products are proudly designed and produced with the highest performance and quality in mind. As a result, each ViewZ monitor is backed by 3-Year parts and labor warranty. In the rare event that one of our products does not perform according to our specifications, ViewZ may also provide an advanced replacement unit.

ViewZ mounts are built with commercial grade for pan rotation, tilting and low profile.

Industry standard VESA mounting patterns with
XMS – MIN. 200 x 200 mm (7.87″ x 7.87″) and MAX. 800 x 400 mm (31.49″ x 15.74″)
WM71 – MIN. 400 x 400 mm (15.74″ x 15.74″) and MAX. 800 x 600 mm (31.49″ x 23.62″)
FSM2x2 & FSM3x2 – MIN. 100 x 100 mm (3.93″ x 3.93″) and MAX. 600 x 400 mm (23.62″ x 15.74″)

Ultra slim distance to the wall.
