VZ-AM02-A
VZ-AM02-A is a fully articulating VESA wall mount. It features simple assembly and fluid movement for easy screen positioning. This high-grade steel mount has a weight capacity of 44 pounds and holds monitor sizes 10” to 43”. Features include +5° to -12° degree screen tilt and +90° to -90° degree monitor swivel for creating best viewing angles, and a cable management system to hold power and video cords.
- 10″~43″ ViewZ Monitors
- Load Capacity is 44 lbs / 20 kg
- +5° ~ -12° tilt, 180° swivel to portrait rotate plate
- VESA : 75×75, 100×100, 200×100, 200×200
Specification | Dimension | Spec & Manual
Series : Wall Mount | Key Features : Compatible for 10-43″ Monitors VESA
Compatible Monitors
Product Features
- Model Number: VZ-AM02-A
- 10″ ~ 43″ Swing Out Double Articulating Wall Mount
- Load Capacity is 44 lbs / 20 kg
- 5° Tilt Up and 12° Tilt Down Adjustment along with 180° Pan
Rotation For Achieving that Perfect Viewing Angle - VESA: 75×75, 100×100, 200×100, 200×200
- 3-Year Warranty
Specification
| Total Weight Capacity | 44 lbs / 20 kg |
| Display Range | 10″ ~ 43″ |
| PAN Rotation (Swivel) | ± 90° |
| Tilt Capability | -12° ~ +5° |
| Mounting Patterns Type | VESA |
| Mounting Patterns | 75×75, 100×100, 200×100, 200×200 |
Dimensions & Weight
| Outline Dimension (W x H x D(Profile)) | 9.0” x 8.4” x (2.3 ~ 14)” / 228.6 mm x 213.4 mm x (58.42 ~ 355.6) mm |
| Net Weight | 4.5 lbs / 2.04 kg |
Product Dimension & Weight
Click below to enlarge
