VZ-19CMP
Full HD CCTV monitor for professional security, digital signage and more
- Full HD 1080p Resolution
- 1 CVBS(BNC) Input / Output (Loop-through)
- 16:9 / 4:3 Ratio Available
- Auto Source & Power Recovery
- AC 100-240V, 50/60Hz (with DC Adaptor) & DC 24V (1.5 A)
- HDMI, VGA, PC/AV Audio
- 3D Comb-Filter, De-Interlace, Built-in Speakers
- Built to run 24/7/365
- 3-Year Warranty
- NDAA Compliant
Specification | Dimension | Spec & Manual
Series : CMP | Key Features : 16:9 / 4:3 Full HD
Compatible Mounts & Accessories
Product Features
- Model Number: VZ-19CMP
- 19.5″ Black Panel Widescreen LED “A” Commercial-Grade Monitor
- HD (1920×1080) / 16:9
- 1 CVBS(BNC) Input / 1 CVBS(BNC) Output (Loop-through)
- 3D Comb-Filter / De-Interlace
- HDMI / VGA / PC Audio In/ AV Audio In
- Auto Source & Power Recovery
- 3W Speaker x 2
- AC 100-240V, 50/60Hz (with DC 24V / 2A Adaptor) / Power Consumption ≤ 24 W
- Built to run 24/7/365
- 3-Year Warranty
- NDAA Compliant
Display
| Screen Size | 19.5″ |
| Max Resolution | 1920 x 1080 @60Hz |
| Pixel Pitch | 0.2265 mm x 0.2265 mm |
| Brightness | 200 cd/m²(Typical) |
| Contrast Ratio | 3000 : 1 |
| Aspect Ratio | 16 : 9 |
| Viewing Angle (H/V) | 176°/176° |
| Display Color | 16.7 Million |
| Response Time | < 25 ms |
Interface
| CVBS (BNC) In / Out | 1 / 1 |
| HDMI In | 1 |
| VGA In (15Pin D-Sub) | 1 |
| PC Audio In / AV Audio In | 1 / 1 |
Audio
| Built in speaker | 3W x 2 |
Special Features
| Filter Type | 3D Comb-filter / De-Interlace |
| Multi-Lingual Language | English, Deutsch, French, Spanish, Italian |
Dimensions & Weight
| Outline Dimension (W x H x D) | 18.42” x 13.38” x 1.92” / 467.9 mm x 339.9 mm x 49.0 mm |
| Net Weight | 8.37 lbs / 3.8 kg |
| Gross Weight | 9.25 lbs / 4.2 kg |
Mount
| Vesa | 100 mm x 100 mm / M4 x L8 mm |
General Summary
| Transmitter – IR Remote Control | Yes |
| Power – Electrical Ratings | AC 100-240V, 50/60Hz (with DC Adaptor), DC 24V / 2.0 A |
| Power – Consumption | ≤ 24 w |
| Regulations | FCC(A), CE, WEEE |
| Operating Temperature | Humidity | 14°F ~ 122°F / -10°C ~ 50°C | 20 ~ 70% RH |
| Compatible Mounts – Wall | VZ-WM05, VZ-WM11, VZ-AM01, VZ-AM02-A |
| Compatible Mounts – Ceiling | VZ-CMKiT-01 |
| Compatible Mounts – Rack | VZ-RMK08 |
Product Dimension & Weight
Click below to enlarge
