VZ-SCM-N
- 17 to 32″ ViewZ Monitors
- Load Capacity is 17.6 lbs / 7.98 kg
- VESA – 75×75, 100×100
- ± 30° Tilt up/down, 180° Panning, 360° Pivot Rotation
Specification | Dimension | Spec & Manual
Series : Pole Mount | Key Features : VESA Mounting Head
Compatible Monitors
Product Features
- Model Number: VZ-SCM-N
- 17 ~ 32″ Tilt and Rotate Wall Mount
- ±30° Tilt Up & Down, 180° Panning (Swivel), 360° Pivot Rotation Adjustment along with Achieving that Perfect Viewing Angle
- VESA Standard 75×75, 100×100
- Load Capacity is 17.6 lbs / 7.98 kg
- White Metal
Specification
Display Range | 17″ ~ 32″ |
Weight Capacity | 17.6 lbs / 7.98 kg |
Tilt Capability | -30° ~ +30° |
Panning Capability | 180° |
Pivot Rotation | 360° |
Mounting Pattern Type | VESA |
Mounting Patterns | 75×75, 100×100 |
Dimensions & Weight
Plate Size (W x H x D) | 194.05 x 128 x 106.93 ~ 392 mm / 7.64″ x 5.04″ x 4.21 ~ 12″ |
Net Weight | 2.59 lbs / 1.17 kg |
Product Dimension & Weight
Click below to enlarge
