VZ-27CGM
27`` 1920x1080 16:9 FHD R1500 Curved Security Monitor
- 27” Curved LED Panel
- Supports Full HD (1920×1080) Resolution
- Display Port (1.2) In x2, HDMI (2.0) In x2, Audio Out x1
- Ultrawide 1500R Curved Screen
- High Response Time – 1ms / Support MPRT
- Supports HDR 10
- 1-Year Warranty
- NDAA Compliant
Specification | Dimension | Spec & Manual
Series : CGM | Key Features : Curved Monitor Full HD
Compatible Mounts & Accessories
Product Features
- Model Number: VZ-27CGM
- 27” Curved LED Panel
- Supports Full HD (1920×1080) Resolution
- Ultrawide 1500R Curved Screen
- High Response Time – 1ms / Support MPRT
- Supported Display Port (1.2) In x2, HDMI (2.0) In x2, Audio Out x1
- Supports HDR
- Wide Viewing Angle (IPS Panel)
- 2W Speaker x 2
- 1-Year Warranty
- NDAA Compliant
Display
| Screen Size | 27″ |
| Max Resolution | 1920 x 1080 |
| Pixel Pitch | 0.3114 mm x 0.3114 mm |
| Brightness | 350cd/m²(Typical) |
| Contrast Ratio | 3000 : 1 |
| Aspect Ratio | 16 : 9 |
| Viewing Angle (H/V) | 178°/178° |
| Display Color | 16.7 Million |
| Response Time | < 1 ms |
Interface
| HDMI In | 2 |
| Display Port In | 2 |
| Audio Out | 1 |
Audio
| Built in speaker | 2W x 2 |
Special Features
| DDC/CI (Command) | Support |
| MPRT (Moving Picture Response Time) | Support |
| Advanced DCR (Dynamic Contrast Ratio) | Support |
| Adaptive Sync | Support |
| Blue Light Filter | Support |
Dimensions & Weight
| Outline Dimension (W x H x D) with Stand | 24.0” x 17.1” x 7.0” / 608.8 mm x 434.5 mm x 179 mm |
| Outline Dimension (W x H x D) without Stand | 24.0” x 14.1” x 2.6” / 608.8 mm x 359.1 mm x 65.9 mm |
| Net Weight | 7.7 lbs / 3.5 kg |
| Gross Weight | 11.28 lbs / 5.11 kg |
Mount
| Vesa | 100 mm x 100 mm (M 6) |
General Summary
| Power – Electrical Ratings | DC 12V (AC100 ~ 240V (50/60Hz)) / 4A |
| Power – Consumption | ≤ 32 w |
| Regulations | FCC(A), CE, RoHS |
| Operating Temperature | Humidity | 32 – 122°F / 0°C ~ 50°C | 20 ~ 85% RH |
| Compatible Mounts – Wall | VZ-AM02-A |
| Compatible Mounts – Ceiling | VZ-CMKiT-01, VZ-CMKiT-02, VZ-CM308 |
Product Dimension & Weight
Click below to enlarge
