VZ-19RTN-ME
19`` Clinical Review High-Performance Display
- 19” LED CCTV Monitor / 1280 x 1024 Resolution
- 2 BNC (Composite) Input / 1 BNC (Composite) Output (Loop-through)
- 16:9 / 4:3 Ratio Available
- Auto Source & Power Recovery
- HDMI, VGA, Audio In/Out
- 3D Comb-filter, De-Interlace, Built-in Speakers
- Built to run 24/7/365
- Medical Safety Power Supply Approved (2 x MOPP)
according to ANSI/AAMI ES60601-1 and IEC/EN60601-1 - 3-Year Warranty
Specification | Dimension | Spec & Manual
Series : RTN-ME | Key Features : 4:3 Monitor Loop Through
Compatible Mounts & Accessories
Product Features
- Model Number: VZ-19RTN-ME
- 19″ Black Flat Panel LED “A” Commercial-Grade Monitor
- 1280 x 1024 / 4:3 (16:9) Available
- 2 BNC(Composite) Inputs / 1 BNC (Composite) Output (Loop-through) /HDMI / VGA / Audio In/Out
- 3D Comb-Filter / De-Interlace
- OSD / Remote Control
- Auto Source & Power Recovery
- 2.5W Stereo Speaker x 2
- Built to run 24/7/365
- Medical Safety Power Supply Approved (2 x MOPP)
according to ANSI/AAMI ES60601-1 and IEC/EN60601-1 - 3-Year Warranty
Display
| Screen Size | 19″ |
| Max Resolution | 1280 x 1024 @60Hz |
| Pixel Pitch | 0.294 mm x 0.294 mm |
| Brightness | 250 cd/m²(Typical) |
| Contrast Ratio | 1000 : 1 |
| Aspect Ratio | 5 : 4 |
| Viewing Angle (H/V) | 170°/160° |
| Display Color | 16.7 Million |
| Response Time | < 5 ms |
Interface
| HDMI In | 1 |
| AV (Composite) In / Out | 2 / 1 |
| VGA In (15Pin D-Sub) | 1 |
| Audio In / Out | 1 / 1 |
Audio
| Built in speaker | 2.5W x 2 |
Special Features
| Filter Type | 3D Comb-filter / De-Interlace |
| Multi-Lingual Language | English, German, French, Spanish, Italian |
Dimensions & Weight
| Outline Dimension (W x H x D) | 16.77” x 16.09” x 5.39” / 426.10 mm x 408.9 mm x 136.97 mm |
| Net Weight | 6.17 lbs / 2.8 kg |
| Gross Weight | 7.27 lbs / 3.3 kg |
Mount
| Vesa | 75 mm x 75 mm (M4 x L8) |
General Summary
| Transmitter – IR Remote Control | Yes |
| Power – Electrical Ratings | DC 12V, 3A (AC 100-240V, 50/60Hz) – Medical Safety Power Supply Approved (2 x MOPP) according to ANSI/AAMI ES60601-1 and IEC/EN60601-1 |
| Power – Consumption | ≤ 23 w |
| Regulations | FCC(A), CE |
| Operating Temperature | Humidity | 14°F ~ 122°F / -10°C ~ 50°C | 20 ~ 70% RH |
