Monitor Enclosure

product Description
vz32wpc2
vz32wpc3
vz32wpc4
vz32wpc5
vz32wpc8
vz32wpc7
vz32wpc2 vz32wpc3 vz32wpc4 vz32wpc5 vz32wpc8 vz32wpc7

VZ-WPC

Experience the elegance of Peerless-AV's outdoor monitor enclosure, designed to support the LED displays and touchscreen panels up to 4`` deep.

  • 32” ~ 49″ Monitor Metal Enclosure
  • Can be used in portrait or landscape with no need for additional hardware
  • Exclusive ThermaVent™ Technology allows enclosure to be mounted directly to the wall with no stand-off bracket
  • Mounts to walls, ceiling adapters and floor stands with no additional hardware
  • High-performance, premium powder coat finish protects the unit and extends the product lifespan for years
  • Stand-alone or fully integrated with display, audio components, media player and input components
  • Internal micro-adjustments allow for quick positioning of display
  • 3-Year Warranty

Specification | Dimension | Spec & Manual

Series : WPC | Key Features : Metal Monitor Enclosure

Compatible Medical Monitors

null
null

Features

Product Features

  • Can be used in portrait or landscape with no need for additional hardware
  • Exclusive ThermaVent™ Technology allows enclosure to be mounted directly to the wall with no stand-off bracket
  • Mounts to walls, ceiling adapters and floor stands with no additional hardware
  • Comes standard with a .25″-thick non-glare acrylic screen
  • Includes 2 ambient-air fans with filtered intake
  • Includes universal mounting bracket for 32″ ~ 55″ flat panels
  • Silicone-sealed knockouts for power / video feed

Specification

VZ-32WPC | General Summary

Display Range 32″ ~ 40″
Weight Capacity 160 lbs / 73kg
Enclosure Size (W x H x D) 1143.0 mm x 762.0 mm x 300.0 mm / 45.0″ x 30.0″ x 11.85″
Panel Hole Size (W x H) 889.0 mm x 501.0 mm / 35″ x 19.75″
Mounting Patterns 200 x 200mm (Min) – 490 x 360 mm (Max)
Temperature Rating Standard 2 Fans for temperatures between 60-80°F
4 Fans for temperatures between 80-100°F
6 Fans for temperatures over 100°F

VZ-50WPC | General Summary

Display Range 42″ ~ 46″
Weight Capacity 160 lbs / 73kg
Enclosure Size (W x H x D) 1403.35 mm x 1003.30 mm x 300.0 mm / 55.25″ x 39.50″ x 11.85″
Panel Hole Size (W x H) 1022.35 mm x 623.30 mm / 40.25″ x 24.50″
Mounting Patterns 200 x 200mm (Min) – 800 x 505mm (Max)
Temperature Rating Standard 2 Fans for temperatures between 60-80°F
4 Fans for temperatures between 80-100°F
6 Fans for temperatures over 100°F

Dimension

Product Dimension & Weight

Click below to enlarge
product Details
