VZ-32MSD
ViewZ surgical display is a kind of medical display of medical endoscopy display and surgery monitoring design. Adopting the global top medical IPS LCD screen, high brightness, contrast ratio, resolution, wide viewing angle, distinct layers. Support dynamic image real-time display, can capture the image one-click, realize screen freezes. Using completely new appearance design, waterproof, anti-bacterial, thinner and lighter than the traditional device screen. Suitable for multiple complex environment in the hospital, meet the surgery display needs.
- 3840 x 2160 @60Hz 4K Resolution
- Input: VGA, DVI, S-Video, SDI,CVBS (BNC), YPbPr, RGB, RS232, USB
- Output: DVI, S-Video, SDI, CVBS (BNC), YPbPr
- Nano Fouling Resistant Coating
- Freeze, Purification Requirement
- Wide Color Space & High Brightness
- High Resolution Improve the Working Flow
- CE & FCC Listed
- Built to run 24/7/365
- Factory Lifetime Limited Warranty
Specification | Dimension | Spec & Manual
Series : MSD | Key Features : Surgical Display
Product Features
- Model Number: VZ-32MSD
- 32″ Black Panel Widescreen LED “A” Commercial-Grade Monitor
- Wide Color Space
- High Resolution Improve the Working Flow
- High Brightness
- Nano Fouling Resistant Coating
- Freeze, Purification Requirement
- 4K (3840 x 2160)
- Input: VGA, DVI, S-Video, SDI,CVBS (BNC), YPbPr, RGB, RS232, USB
- Output: DVI, S-Video, SDI, CVBS (BNC), YPbPr
- CE & FCC Listed
- Auto Source & Power Recovery
- Built to run 24/7/365
- Factory Lifetime Limited Warranty
Display
| Screen Size | 32″ |
| Max Resolution | 3840 x 2160 @60Hz |
| Pixel Pitch | 0.181 mm x 0.181 mm |
| Brightness | 650 cd/m²(Typical) |
| Contrast Ratio | 1700 : 1 |
| Aspect Ratio | 16 : 9 |
| Viewing Angle (H/V) | 178°/178° |
| Display Color | 16.7 Million |
| Response Time | < 9.5 ms |
Interface
| DVI In / Out | 1/1 |
| S-Video In / Out | 1/1 |
| VGA In | 1 |
| SDI In / Out | 1/1 |
| CVBS (BNC) In / Out | 1/1 |
| YPbPr In / Out | 1/1 |
| RGB In | 1 |
| RS232 In | 1 |
| USB In | 1 |
Special Features
| Wide Color Space | Support |
| Display Surface Treatment | ANTI-Dazzle |
Dimensions & Weight
| Outline Dimension (W x H x D) | TBD |
| Net Weight | TBD |
General Summary
| Power – Electrical Ratings | TBD |
| Power – Consumption | ≤ 160 w |
| Regulations | FCC(A), CE, RoHs |
| Operating Temperature | Humidity | 14°F ~ 122°F / -10°C ~ 50°C | 5 ~ 90% RH |
Product Dimension & Weight
Click below to enlarge
