    • 55” 1080p CCTV LED Monitor / 1.07B color IPS Panel
    • Narrow 5.9 mm Metal Bezel
    • High Brightness 700 cd/m²
    • Digital & Analog Inputs
    • USB - Media Player
    • Auto Source & Power Recovery
    • 3D Comb-Filter & De-Interlace
    • Prevents Pixel Burn-In
    • 3-Year Warranty
Hover to zoom, click to view

Compatible Mounts

Model Number: VZ-55NB
55" Flat Panel Widescreen LED A Commercial-Grade Monitor

55" Black All Metal 5.9 mm Narrow Seamless Bezel

1.07 Billion Color IPS Panel (10 bit)
Full HD 1920x1080 / 16:9
HDMI / DVI / VGA / USB / AV (composite) / S-Video(Y,C-BNC) / RCA (Audio) In&Out / PC Stereo In / Rs-232 IN
3D Comb Filter / De-Interlace
Auto Power and Source Recovery
10W Speaker x 2
AC100 ~ 240V(50/60Hz)
3-Year Warranty













Download VZ-55NB PDF Specifications Sheet

Download VZ-55NB PDF Manual
















  Screen Size 55"
  Max Resolution 1920 x 1080 @60Hz
  Bezel Width (Active area to Active area) 0.46" (11.8 mm)
  Pixel Pitch 0.630mm x 0.630mm
  Brightness 700cd/m²(Typical)
  Contrast Ratio 1300:1
  Aspect Ratio 16 : 9
  Viewing Angle (H/V) 178°/178°
  Display Color 1.07 Billion
  Response Time < 8ms
  Video System NTSC / PAL


  VGA In (15Pin D-Sub) 1
  DVI-D In 1
  HDMI In 1
  USB In 2
  AV (Composite) In / Out 4 / 1
  Component (Y, Pb, Pr - BNC) In 1
  S-Video (Y, C - BNC) In 1
  RS-232 In / Out 1 / 1
  RCA (Audio) In / Out 1 / 1
  PC Stereo In 1


  Built-in Speaker 10 W x 2


  Video Codec WMA/WMV, AAC, AC3, DIVX, MPEG, H264, VC1, AVS, FLV, RM/RMVB
  Video Format MPEG, AVI, MOV, MP4, MKV, RM, RMVB
  Image Format JPEG, PNG, BMP
  Music Format mp3, mp4, wma
  Text Format TXT (raw text file only)
  Support Capacity Max 16GB


  RS-232 Control Monitor Power On / Off
  Prevent Pixel Burn-in YES
  Source & Power Recovery YES
  3D Comb-Filter & De-Interlace YES
  Multi-Lingual Language English, Chinese


  Outline Dimension 48.32" x 27.48" x 3.42"
  (W x H x D) 1227.40mm x 698.20mm x 87.10mm
  Net Weight 66.91 lbs / 30.35kg
  Gross Weight 83.77 lbs / 38.0kg


  Universal 600mm x 94mm x 200mm x 94mm / M6 X L12 Screws


  Transmitter - IR Remote Control Yes
  Power - Electrical Ratings AC100 ~ 240V(50/60Hz)
  Power - Consumption 150 W (Max) / 1.25 W (Standby)
  Warranty - Parts / Labor 3 Year / 3 Year
  Operating Temperature 32 - 122°F / 0 - 50°C
  Compatible Mounts - Wall VZ-XM55, VZ-WM71
  Compatible Mounts - Ceiling VZ-CMK04, VZ-CMKit04





  * Specifications subject to change without notice
