Designing & Manufacturing Premium Display Solutions

ViewZ consists of over 120 commercial-grade monitor models that are used in security, broadcast & post production, digital signage and gaming industries.
All backed by our 3-year factory warranty, ViewZ is trusted around the world in casinos, financial institutions, government agencies and Fortune 500 retailers.

SECURITY   |    BROADCAST   |    LENSES   |    DIGITAL SIGNAGE   |    MEDICAL

  • 4K UHD  HD PVM N  IP PVM N   IPM   PRO  NB  RTC  RTN  LX  RCR  CME/CMP  Hybrid CMX Monitor
    • 49” 1080p CCTV LED Monitor / 1.07B color IPS Panel
    • Extreme-narrow 0.9 mm Metal Bezel
    • 700 cd/m² High Brightness
    • Digital & Analog Inputs
    • USB - Media Player
    • Auto Source & Power Recovery
    • 3D Comb-Filter & De-Interlace
    • Prevents Pixel Burn-In
    • 3-Year Warranty
    • Hover to zoom, click to view

    Compatible Mounts

    Model Number: VZ-49EHB
    49" Flat Panel Widescreen LED A Commercial-Grade Monitor

    49" Black All Metal 0.9 mm Extreme-narrow Seamless Bezel

    700 cd/m² High Brightness
    1.07 Billion Color IPS Panel (10 bit)
    Full HD 1920x1080 / 16:9
    HDMI / DVI / VGA / USB / AV (composite) / S-Video(Y,C-BNC) / RCA (Audio) In&Out / PC Stereo In / RS-232 IN
    3D Comb Filter / De-Interlace
    Auto Power and Source Recovery
    10W Speaker x 2
    AC100 ~ 240V(50/60Hz)
    3-Year Warranty













    Download VZ-49EHB PDF Specifications Sheet

    Download VZ-49EHB PDF Manual
















      Screen Size 49"
      Max Resolution 1920 x 1080 @60Hz
      Bezel Width (Active area to Active area) 0.070” / 1.8 mm
      Pixel Pitch 0.630mm x 0.630mm
      Brightness 700cd/m²(Typical)
      Contrast Ratio 1300:1
      Aspect Ratio 16 : 9
      Viewing Angle (H/V) 178°/178°
      Display Color 1.07 Billion
      Response Time < 8ms
      Video System NTSC / PAL


      VGA In (15Pin D-Sub) 1
      DVI-D In 1
      HDMI In 1
      USB In 2
      AV (Composite) In / Out 4 / 1
      Component (Y, Pb, Pr - BNC) In 1
      S-Video (Y, C - BNC) In 1
      RS-232 In / Out 1 / 1
      RCA (Audio) In / Out 1 / 1
      PC Stereo In 1


      Built-in Speaker 10 W x 2


      Video Codec WMA/WMV, AAC, AC3, DIVX, MPEG, H264, VC1, AVS, FLV, RM/RMVB
      Video Format MPEG, AVI, MOV, MP4, MKV, RM, RMVB
      Image Format JPEG, PNG, BMP
      Music Format mp3, mp4, wma
      Text Format TXT (raw text file only)
      Support Capacity Max 16GB


      RS-232 Control Program Monitor Power On / Off
      Prevent Pixel Burn-in YES
      Source & Power Recovery YES
      3D Comb-Filter & De-Interlace YES
      Multi-Lingual Language English, Chinese


      Outline Dimension 42.34” x 23.85” x 4.45”
      (W x H x D) 1075.58mm x 605.8mm x 113.1mm
      Net Weight 56.65 lb / 25.7 kg
      Gross Weight 74.51 lb / 33.8 kg


      Universal 600 x 400 mm, (M6 x L12) x 4 Screws


      Transmitter - IR Remote Control Yes
      Power - Electrical Ratings AC100 ~ 240V(50/60Hz)
      Power - Consumption 150 W (Max) / 0.5 W (Standby)
      Warranty - Parts / Labor 3 Year / 3 Year
      Operating Temperature 32 - 104°F / 0 - 40°C
      Compatible Mounts - Wall VZ-XMS, VZ-WM71
      Compatible Mounts - Ceiling VZ-CMK04, VZ-CMKit04





      * Specifications subject to change without notice
