Designing & Manufacturing Premium Display Solutions

ViewZ consists of over 120 commercial-grade monitor models that are used in security, broadcast & post production, digital signage and gaming industries.
All backed by our 3-year factory warranty, ViewZ is trusted around the world in casinos, financial institutions, government agencies and Fortune 500 retailers.

SECURITY   |    BROADCAST   |    LENSES   |    DIGITAL SIGNAGE   |    MEDICAL

  • 4K UHD  HD PVM N  IP PVM N   IPM   PRO  NB  RTC  RTN  LX  RCR  CME/CMP  Hybrid CMX Monitor
    • 46” 1080p CCTV LED Monitor
    • Ultra-narrow 1.4 mm Metal Bezel
    • Digital & Analog Inputs
    • USB - Media Player
    • Auto Source & Power Recovery
    • 3D Comb-Filter & De-Interlace
    • Prevents Pixel Burn-In
    • 3-Year Warranty
Hover to zoom, click to view

Compatible Mounts

Model Number: VZ-46UNB
46" Flat Panel Widescreen LED A Commercial-Grade Monitor

46" Black All Metal 1.4 mm Ultra-narrow Seamless Bezel

Full HD 1920x1080 / 16:9
HDMI / DVI / VGA / USB / AV (composite) / S-Video(Y,C-BNC) / RCA (Audio) In&Out / PC Stereo In / Rs-232 IN
3D Comb Filter / De-Interlace
Auto Power and Source Recovery
10W Speaker x 2
AC100 ~ 240V(50/60Hz)
3-Year Warranty













Download VZ-46UNB PDF Specifications Sheet

Download VZ-46UNB PDF Manual
















  Screen Size 46"
  Max Resolution 1920 x 1080 @60Hz
  Bezel Width (Active area to Active area) 3.9 mm
  Pixel Pitch 0.53025mm x 0.53025mm
  Brightness 500cd/m²(Typical)
  Contrast Ratio 3500:1
  Aspect Ratio 16 : 9
  Viewing Angle (H/V) 178°/178°
  Display Color 16.7 Million
  Response Time < 8ms
  Video System NTSC / PAL


  VGA In (15Pin D-Sub) 1
  DVI-D In 1
  HDMI In 1
  USB In 2
  AV (Composite) In / Out 4 / 1
  Component (Y, Pb, Pr - BNC) In 1
  S-Video (Y, C - BNC) In 1
  RS-232 In / Out 1 / 1
  RCA (Audio) In / Out 1 / 1
  PC Stereo In 1


  Built-in Speaker 10 W x 2


  Video Codec WMA/WMV, AAC, AC3, DIVX, MPEG, H264, VC1, AVS, FLV, RM/RMVB
  Video Format MPEG, AVI, MOV, MP4, MKV, RM, RMVB
  Image Format JPEG, PNG, BMP
  Music Format mp3, mp4, wma
  Text Format TXT (raw text file only)
  Support Capacity Max 16GB


  RS-232 Control Program Monitor Power On / Off
  Prevent Pixel Burn-in YES
  Source & Power Recovery YES
  3D Comb-Filter & De-Interlace YES
  Multi-Lingual Language English, Chinese


  Outline Dimension 40.23" x 22.69" x 4.68"
  (W x H x D) 1021.98mm x 576.67mm x 119.0mm
  Net Weight 46.29 lb / 21.0 kg
  Gross Weight 61.72 lb / 28.0 kg


  Universal 600mm x 94mm x 200mm x 94mm / M6 X 12 Screws


  Transmitter - IR Remote Control Yes
  Power - Electrical Ratings AC100 ~ 240V(50/60Hz)
  Power - Consumption 140 W (Max) / 0.5 W (Standby)
  Warranty - Parts / Labor 3 Year / 3 Year
  Operating Temperature 32 - 122°F / 0 - 50°C
  Compatible Mounts - Wall VZ-XM46, VZ-WM71
  Compatible Mounts - Ceiling VZ-CMK04, VZ-CMKit04





  * Specifications subject to change without notice
