Model Number: VZ-98IBX-T |
|
97.52" LED UHD Panel |
|
4K Resolution - 3840x2160 / 16:9 | |
Wide Viewing Angle (IPS Panel) | |
Multi Touch Screen | |
HDMI & AV Loop-through | |
USB - Media Player | |
Auto Source Recovery | |
Supported HDMI (2.0 & 1.4), YPbPr, AV, SPDIF & VGA | |
1300:1 Contrast Ratio |
Download VZ-98IBX-T PDF Specifications Sheet
Screen Size | 97.52" |
Max Resolution | 3840x2160 @60Hz |
Active Display Area (H/V) | 0.5622 mm x 0.5622 mm |
Brightness | 500cd/m²(Typical) |
Contrast Ratio | 1300:1 |
Aspect Ratio | 16 : 9 (1.78:1) |
Viewing Angle (H/V) | 178°/178° |
Display Color | 1.07 G (8-bit + FRC) |
Response Time | < 8ms |
HDMI (2.0) In / Out | 4 / 1 |
HDMI (1.4) In | 1 |
YPbPr In | 1 |
AV In / Out | 1 / 1 |
VGA In (15pin D-Sub) | 1 |
SPDIF (Optical) Out | 1 |
RS232 (RJ-45) In | 1 |
USB In (Media) | 5 ( USB 3.0 x 3 | USB 2.0 x 2 ) |
USB In (Under OPS - Mouse, Keyboard, U-Disk) | 2 |
USB In (Touch) | 1 |
RJ45 (10/100M) In | 1 |
Audio Out | 1 |
PC Audio In | 1 |
Built-in Speaker | 15 W x 2 |
Sensor Type | Infrared Touch Frame |
Surface Protection | 5mm Toughened Glass |
Response Time | < 15ms |
Touch Accuracy | 90% ± 2mm |
Output Mode | HID Standard |
Theory Clicks | Unlimited |
Theory Object | ≥ 6 mm |
Video Codec | MPEG1/2, MPEG4, DivX 3.11/4.12/5.x/5, XviD,H.263, H.264, MVC, AVS, WMV3, VC1, Motion JPEG, VP 8/9, RV30/40 |
Video Format | MPEG, AVI, MOV, MP4, MKV, RM, 3GP, FLV, WebM, ASP |
Image Format | JPEG, PNG, BMP |
Music Format | mp3, mp4, wma |
Support Capacity | Max 32GB |
Image Retention | Yes |
Outline Dimension | 88.25” x 52.66” x 4.58” |
(W x H x D) | 2241.66 mm x 1337.8 mm x 116.4 mm |
Net / Gross Weight | 307.39 lbs (139.43kg) / 424.72 lbs (192.65kg) |
Universal | 800 x 600 mm / |
4 x M8 screws | |
Power - Electrical Ratings | AC100~240V (50/60Hz) |
Power - Consumption | 480 W (Max) / 0.5 W (Standby) |
Warranty - Parts / Labor | 3 Year |
Operating Temperature | 32 ~ 104°F / 0 ~ 40°C |
Operating Humidity | 20~80% RH |
Storage Temperature | 14 ~ 140°F / -10 ~ 60°C |
Storage Humidity | 10%~60% RH |
* Specifications subject to change without notice |
