Lens Calculator
1. Choose Camera Image Size. 2. Enter object distance. 3. Enter horizontal view needed. 4. Click the Calculate button to display focal length needed



Object Distance   ft
Horizontal View Needed   ft


Focal Length Needed   mm

MP Vari-Focal Day/Night Lense Lineup





MODEL Series/Resolution Format Focal Length F.NO. / IRIS Mount
VZ-A338VDCIR-MP 1.3MP 1 / 3" 3.3 - 8 mm F1.4 / DC CS
VZ-A212VDCIR-3MP 3MP 1 / 3" 2.8 - 12 mm F1.4 / DC CS
VZ-B880VIR-MP 1.5MP 1 / 2" 8 - 80 mm F1.6 / Manual C
VZ-B880VDCIR-MP 1.5MP 1 / 2" 8 - 80 mm F1.6 / DC C
VZ-F312AVDCIR-3MP 3MP 1 / 2.7" 3.1 - 12 mm F1.5 / DC CS
VZ-F850AVDCIR-5MP 5MP 1 / 2.7" 8 - 50 mm F1.6 / DC CS


Scroll to learn more

Key Features























HIGH QUALITY LENSES



To achieve the full resolution of a megapixel camera, it is essential to use a high quality megapixel lens. Overall image quality is greatly affected by the quality of the optical image directed onto the image sensor.



ViewZ Megapixel lenses provide high contrast, brightness and sharpness across the entire image plane. Non-megapixel lenses will not fully display the resolution of megapixel sensor, especially in the corner areas of the image.



Back to Features












MEGAPIXEL VARI-FOCAL LENS



ViewZ Megapixel vari-focal lenses offer the maximum flexibility when the installation setting requires a wide range of focal lengths. The focal length can be adjusted easily on all lenses and comes with either manual iris, for installations with constant light conditions, or with auto-iris for settings with changing light conditions. We offer a wide range of vari-focal lenses, including megapixel and IR (Day/Night).



Some models utilize ED (Extra-low Dispersion) glass and aspherical lens technology to pave the way for more possibilities in high end surveillance applications. ED glass helps to correct chromatic aberrations, or color fringing, caused when different light wavelengths do not converge at the same point after passing through traditional optical glass. ED glass improves sharpness and contrast in standard and IR lighting applications, even at maximum aperture.



Back to Features






















24 / 7 SURVEILLANCE APPLICATION



There is a growing need for compact, high quality lenses for 24/7 surveillance applications such as parking lots, factory premises and streets. Continuous surveillance is also required for public facilities such as airports, harbors, highways and border patrol, requiring more versatile focal lengths and higher zoom ratios.



ViewZ Day/Night (IR) lenses respond to infrared illumination to capture clear, corrected images in all lighting conditions. We offer a lineup of lenses from the standard focal length of 2.8-12 mm to the diverse focal length of 8-80mm featuring ED (Extra-low Dispersion) glass for maximum focus shift correction under IR and excellent daytime performance.





Back to Features
















MADE IN JAPAN



All ViewZ lenses are all made in JAPAN and we produce superior quality products in a small-sized manufacturing environment, where we respect craftsmanship.



Viewz offers over 180 advanced lens solutions such as Fixed, Vari-Focal, and Zoom in both standard and megapixel resolutions for a variety of applications. Each ViewZ lens is backed by our 4-year warranty.



Back to Features












MANUAL IRIS



An iris that can be manually adjusted for different lighting conditions. This type of lens is normally used for fixed lighting applications or in conjunction with the electronic iris in the camera if the scene lighting level changes.



* VZ-B880VIR-MP



Back to Features










DC-TYPE AUTO-IRIS



An auto-iris lens without an internal circuit to control the iris. All iris control voltages come from a circuit located within the camera to adjust the iris for changing light levels. DC-type lenses are recommended for use in inconsistent lighting conditions (e.g. outdoors). These are sometimes referred to as DD (Direct Drive) lenses.



* VZ-A338VDCIR-MP, VZ-A212VDCIR-3MP, VZ-B880VDCIR-MP



Back to Features










VARIOUS FOCAL LENGTH



Focal length is the basic characteristic of a lens and determines how much magnification it provides. The focal length defines the area of the scene that can be viewed with a given sensor size and is expressed in millimeters (mm).



ViewZ lenses have many options when it comes to focal length selection to fit your application.



Back to Features










C & CS MOUNT



CCTV lenses are available in two different lens mounts. C-mount lenses have a flange back distance of 17.526mm vs. 12.5mm for CS-mount lenses. Many of today’s cameras can accept either type of lens, but it is important to make sure that camera and lens are compatible and set up properly.



C-mount lenses have a flange back distance of 17.526mm vs. 12.5mm for CS-mount lenses. C-mount lenses can be used on CS-mount cameras by utilizing a 5mm adapter or adjusting the camera for C-mount lenses.



CS-mount lenses have a flange back distance of 12.5mm vs. 17.526mm for C-mount lenses. Because of the shorter back focal distance, CS-mount lenses can only be used on CS-mount cameras. Your picture will be out of focus if you use a CS-mount lens on a C-mount camera.





Back to Features




















PEACE OF MIND



ViewZ products are proudly designed and produced with the highest performance and quality in mind. As a result, each ViewZ lens is backed by our 4-year Parts and Labor Warranty. In the rare event that one of our products does not perform according to our specifications or our customer's expectations, ViewZ on-site Technical Support staff will work diligently to resolve each case. ViewZ may also choose to provide an Advanced Replacement unit depending on the details of each individual case.
