ViewZ consists of over 120 commercial-grade monitor models that are used in security, broadcast & post production, digital signage and gaming industries.
All backed by our 3-year factory warranty, ViewZ is trusted around the world in casinos, financial institutions, government agencies and Fortune 500 retailers.
|MODEL||Series/Resolution||Format||Focal Length||F.NO. / IRIS||Mount|
|VZ-C8M-3MP||3MP||2 / 3"||8 mm||F1.4 / Manual||C|
|VZ-C12M-3MP||3MP||2 / 3"||12 mm||F1.8 / Manual||C|
|VZ-C16M-3MP||3MP||2 / 3"||16 mm||F1.4 / Manual||C|
|VZ-C25M-3MP||3MP||2 / 3"||25 mm||F1.4 / Manual||C|
|VZ-C35M-3MP||3MP||2 / 3"||35 mm||F1.4 / Manual||C|
|VZ-C8M-5MP||5MP||2 / 3"||8 mm||F2.8 / Manual||C|
|VZ-C12M-5MP||5MP||2 / 3"||12 mm||F1.8 / Manual||C|
|VZ-C16M-5MP||5MP||2 / 3"||16 mm||F1.4 / Manual||C|
|VZ-C25M-5MP||5MP||2 / 3"||25 mm||F1.4 / Manual||C|
|VZ-C35M-5MP||5MP||2 / 3"||35 mm||F1.4 / Manual||C|
|VZ-BH6M-MP||1.5MP||1 / 2"||6 mm||F1.4 / Manual||C|
|VZ-CH25M-3MP||3MP||2 / 3"||25 mm||F1.4 / Manual||C|
|VZ-CH35M-3MP||3MP||2 / 3"||35 mm||F2.0 / Manual||C|
|VZ-CH50M-3MP||3MP||2 / 3"||50 mm||F2.8 / Manual||C|
|VZ-EH16M-3MP||3MP||1 / 1.8"||16 mm||F1.4 / Manual||C|
|VZ-C8MK-2MP||2MP||2 / 3"||8 mm||F1.4 / Manual||C|
|VZ-C12MK-2MP||2MP||2 / 3"||12 mm||F1.4 / Manual||C|
|VZ-C16MK-2MP||2MP||2 / 3"||16 mm||F1.4 / Manual||C|
|VZ-C25MK-2MP||2MP||2 / 3"||25 mm||F1.4 / Manual||C|
|VZ-C35MK-2MP||2MP||2 / 3"||35 mm||F2.0 / Manual||C|
|VZ-C50MK-2MP||2MP||2 / 3"||50 mm||F2.8 / Manual||C|
|VZ-D8M-3MP||3.1MP||1"||8 mm||F1.4 / Manual||C|
|VZ-D12.5M-3MP||3.1MP||1"||12.5 mm||F1.4 / Manual||C|
|VZ-D16M-3MP||3.1MP||1"||16 mm||F1.4 / Manual||C|
|VZ-D25M-3MP||3.1MP||1"||25 mm||F1.4 / Manual||C|
|VZ-D35M-3MP||3.1MP||1"||35 mm||F1.4 / Manual||C|
|VZ-D50M-3MP||3.1MP||1"||50 mm||F1.4 / Manual||C|
|VZ-D75M-3MP||3.1MP||1"||75 mm||F1.4 / Manual||C|
To achieve the full resolution of a megapixel camera, it is essential to use a high quality megapixel lens. Overall image quality is greatly affected by the quality of the optical image directed onto the image sensor.
ViewZ Megapixel lenses provide high contrast, brightness and sharpness across the entire image plane. Non-megapixel lenses will not fully display the resolution of megapixel sensor, especially in the corner areas of the image.
All ViewZ lenses are all made in JAPAN and we produce superior quality products in a small-sized manufacturing environment, where we respect craftsmanship.
Viewz offers over 180 advanced lens solutions such as Fixed, Vari-Focal, and Zoom in both standard and megapixel resolutions for a variety of applications. Each ViewZ lens is backed by our 4-year warranty.
An iris that can be manually adjusted for different lighting conditions. This type of lens is normally used for fixed lighting applications or in conjunction with the electronic iris in the camera if the scene lighting level changes.
* All ViewZ Megapixel fixed focal length lenses have manual-iris.
Focal length is the basic characteristic of a lens and determines how much magnification it provides. The focal length defines the area of the scene that can be viewed with a given sensor size and is expressed in millimeters (mm).
ViewZ lenses have many options when it comes to focal length selection to fit your application.
CCTV lenses are available in two different lens mounts. C-mount lenses have a flange back distance of 17.526mm vs. 12.5mm for CS-mount lenses. Many of today’s cameras can accept either type of lens, but it is important to make sure that camera and lens are compatible and set up properly.
C-mount lenses have a flange back distance of 17.526mm vs. 12.5mm for CS-mount lenses. C-mount lenses can be used on CS-mount cameras by utilizing a 5mm adapter or adjusting the camera for C-mount lenses.
CS-mount lenses have a flange back distance of 12.5mm vs. 17.526mm for C-mount lenses. Because of the shorter back focal distance, CS-mount lenses can only be used on CS-mount cameras. Your picture will be out of focus if you use a CS-mount lens on a C-mount camera.
ViewZ products are proudly designed and produced with the highest performance and quality in mind. As a result, each ViewZ lens is backed by our 4-year Parts and Labor Warranty. In the rare event that one of our products does not perform according to our specifications or our customer's expectations, ViewZ on-site Technical Support staff will work diligently to resolve each case. ViewZ may also choose to provide an Advanced Replacement unit depending on the details of each individual case.
Lenses from ViewZ USA have been recognized by various customers for providing good value and meeting their needs throughout the world with high standard Japanese quality at global-standard prices. We will continue our research to keep providing high quality and reliable products.
