  • LED  4K UHD  HD PVM N  IP PVM N   IPM   PRO  UNB  RTC  RTN  LX  RCR  CME/CMP  Hybrid CMX Monitor
    • 65” LED ULTRA HD Panel
    • Supports 4K (3840X2160) Resolution
    • Mode 1: Displays 4K (3840X2160) Resolution
    • Mode 2: PBP, PIP & Quad (Each 1080p) PIP
    • MVA Technology & V-by-One® INTERFACE
    • Auto Source / Power Recovery
    • Wide Viewing Angle (IPS Panel)
    • 1.07G Color & QFHD 24/30 or 50/60 Hz
Hover to zoom, click to view


Compatible Mounts


Model Number: VZ-65UHD

65" LED UHD Panel
4K Resolution - 3840x2160 / 16:9
QFHD 24/30 Hz or 50/60 Hz
Wide Viewing Angle (IPS Panel)
Auto Source / Power Recovery
Supported Display Port (1.2) & HDMI (2.0 & 1.4)
4000:1 Contrast Ratio













Download VZ-65UHD PDF Specifications Sheet

Download VZ-65UHD PDF Manual


















  Screen Size 65"
  Max Resolution 3840x2160 @60Hz
  Active Display Area (H/V) 0.374 mm x 0.374 mm
  Brightness 400cd/m²(Typical)
  Contrast Ratio 4000:1
  Aspect Ratio 16 : 9 (1.78:1)
  Viewing Angle (H/V) 178°/178°
  Display Color 1.07 G (8-bit + FRC)
  Response Time < 9.5ms


  Display Port In 1
  HDMI (2.0) In 1
  HDMI (1.4) In 3
  Audio Out (L /R) 1


  Multi Display Function PIP / Dual / Quad
  Image Retention Yes


  Outline Dimension 57.15” x 33.18” x 2.2”
  (W x H x D) 1451.7 mm x 842.9 mm x 55.8 mm
  Net / Gross Weight 127.86 lbs ( 58.0 kg ) / 136.68 lbs ( 62.0 kg )


  Universal 400mm x 400mm
  4 x ( M8 x L12 ) screws


  Display Port HDMI 2.0 HDMI 1.4 HDMI 1.4 HDMI 1.4
Display Port X Ο Ο Ο Ο
HDMI 2.0 Ο X Ο Ο Ο
HDMI 1.4 Ο Ο X Ο Ο
HDMI 1.4 Ο Ο Ο X Ο
HDMI 1.4 Ο Ο Ο Ο X

  Power - Electrical Ratings AC100~240V (50/60Hz)
  Power - Consumption 215W
  Warranty - Parts / Labor 3 Year / 3 Year
  Operating Temperature 32 - 122°F / 0°C ~ 50°C
  Operating Humidity 40~60% RH
  Compatible Mounts - Wall VZ-WM71





  * Specifications subject to change without notice
