Model Number: VZ-23LED-E

23" Black Panel Widescreen LED "A" Commercial-Grade Monitor
Full HD 1920x1080 / 16:9
HDMI / DVI / VGA / PC Stereo
Protection Glass
OSD
2W Speaker x 2
DC 12V
50Khrs
3-Year Warranty













Download VZ-23LED-E PDF Specifications Sheet

Download VZ-23LED-E PDF Dimension Diagram

Download VZ-23LED-E PDF Manual
















  Screen Size 23"
  Max Resolution 1920 x 1080 @ 60Hz
  Pixel Pitch 0.2655 mm x 0.2655 mm
  Brightness 250cd/m²(Typical)
  Contrast Ratio 1000:1
  Aspect Ratio 16 : 9
  Viewing Angle (H/V) 170°/160°
  Display Color 16.7 Million
  Response Time < 5ms
  Frequency (H) 31 ~ 80Khz
  Frequency (V) 56 ~ 75Hz


  RGB In (15pin D-Sub) 1
  DVI In 1
  HDMI In 1
  PC Stereo In 1


  Built-in Speaker 2 W x 2


  Multi-Lingual Language English, Spanish, French, Korean, Dutch


  Outline Dimension 21.57 “ x 16.15 “ x 2.45”
  (W x H x D) 547.9 mm x 410.2 mm x 62.23 mm
  Net Weight 10.05 lbs ( 4.56kg )
  Gross Weight 14.9 Ibs ( 6.76 kg )


  Vesa 100mm x 100mm / M4 x 10 Screws


  Transmitter - IR Remote Control Yes
  Power - Electrical Ratings DC12V, 2.0A (AC100 ~ 240V[50/60Hz])
  Power - Consumption 24W
  Warranty - Parts / Labor 3 Year / 3 Year
  Warranty - MTBF (Approx.) 50,000 Hours
  Operating Temperature 32 - 104°F / 0 - 40°C
  Compatible Mounts - Wall VZ-WM05, VZ-WM11, VZ-AM01
  Compatible Mounts - Ceiling VZ-CMKiT-01, VZ-CMKiT-02, VZ-CMK02





  * Specifications subject to change without notice
